Type:Button Head Torx Machine Screws
Materials:Carbon Steel
Surface treatment:Blue Zinc Plated+Nylok Patch
Head Type:Button Head
Drive:Torx six-lobe recess (T-size matched to the thread)
Thread:Machine thread, rolled 60 degrees, full to the head bearing face
Point:Blunt end with a small chamfer; no taper, no drill point
Forming:Single-die heading, thread rolling, blue zinc plating, nylon patch applied, sorting
Size:M1 M2 M3 M4 M5 M6 M7 M8 M9 M10 M14
Number:791
We manufacture button head torx machine screws with a low domed head, a six-lobe star recess and a dry nylon patch on a defined thread length, in carbon steel with a blue zinc finish. Head, recess, patch zone, thread and length are taken from your drawing.
Watch the factory video·Email sst@szsst88.com
ISO 9001:2015 · Manufacturing since 1998 · 8,678+ customers · 89 countries and regions
Made to order – there is no stock catalogue. Each part is produced to your drawing, and production starts after drawing review and first-article approval.
Button head torx machine screws are machine screws with a low domed button head, a six-lobe star recess and a nylon patch on the thread. The recorded item on this page is carbon steel with a blue zinc finish and a Nylok patch, quoted from M1 to M14 with Number 791.
Button head. A low dome wider than a socket cap head, with no sharp edge and no recessed crown. It spreads load over a broad curved face and reads as smooth from any angle, which is why it is used where the fixing is seen or handled.
Torx recess. Six lobes with straight walls, driven with a matching star bit. The bit engages on six faces and does not cam out the way a cross does, so it can drive the head to a seated torque without marking it.
Nylok patch. A dry nylon patch on a defined length of thread. It compresses as the screw engages and fills the clearance, giving a friction lock that keeps the joint from backing out under vibration.
Blue zinc. A bright blue-white electroplate over the head, the recess and the thread. It is the standard indoor finish for steel fasteners: thin, bright and sacrificial.
Machine thread. A rolled thread for a tapped hole or a nut, with a blunt end. This is not a self-tapping part: the thread it engages already exists.
The button head and the six-lobe recess are formed in one heading stroke. The dome on a button head is shallow, so the recess sits close to the crown; if it is formed off centre, the wall on one side thins and the head deforms under torque instead of driving the thread.
The head diameter on a button head is deliberately wider than a socket cap of the same thread. That width is the bearing area, and it is also the reason the drive has to be a star rather than a cross: a wide dome driven with a cross would need a larger recess than the head height allows.
The thread is rolled and runs to the underside of the head. Rolling work-hardens the flank and gives a smooth surface, which is what lets the nylon patch work without being cut away as the screw is driven in.
The patch is applied after plating, over a defined engaged length. That length has to land inside the tapped hole or nut when the head seats — a patch that stops short of the engagement does nothing, and one that runs onto the lead-in is scraped off before the thread engages.
Blue zinc goes on before the patch, never after. A patch applied over oil or a part oiled afterwards will not hold the friction the drawing assumes, and that failure shows up as a joint that is tight at assembly and loose a shift later.
The family is quoted from M1 to M14, with M1, M2, M3, M4, M5, M6, M7, M8, M9, M10 and M14 in the recorded range. Custom lengths up to 2,000 mm are subject to DFM review after drawing submission; on button head torx machine screws the head width, the thread length and the patch zone are the three numbers that decide the joint.
| Item | How it is defined | What we control |
|---|---|---|
| Head | Button head, low dome | Diameter and height on the projector |
| Recess | Torx six-lobe, sized to the thread | Checked with the production bit |
| Thread | Machine thread, rolled, to the head | Gauged per batch after plating |
| Patch zone | Engaged length over a defined section | Position and length checked per batch |
| End | Blunt with a small chamfer | Checked on the first article |
| Length | From under the head to the end | Measured on the shop plate |
The head width is the number to check against the joint before ordering. A button head covers more area than a socket cap of the same thread, which is an advantage on a thin panel and a problem where fixings sit close together — a row of button heads needs more spacing than a row of cap heads.
The patch zone is the number most often left to the supplier and least often understood. It is quoted as a position and a length measured from the head, and it is checked on the first article against a sample joint rather than against the drawing alone.
Three features define this part, and each of them solves a problem the others do not.
| Feature | What it gives | What it costs |
|---|---|---|
| Button head | Wide bearing area, no sharp edge | Takes more space than a cap head |
| Torx recess | High torque without cam-out or marking | Needs the matching star bit |
| Nylok patch | Friction lock against vibration | Wears with repeated assembly |
| Full thread to the head | Engagement over the whole length | No plain shank to centre the screw |
| Blue zinc | Bright, thin, sacrificial | Indoor only; gives way outdoors |
The button head is chosen for what it does to the surface. There is no sharp edge to catch a cloth or a hand, the dome reflects light evenly so a row of them looks consistent, and the wide face spreads load on a panel that a narrower head would dish. Those are reasons to specify it, and none of them are reasons to specify a socket cap.
The star drive is what makes a domed head usable. A cross recess in a low dome has little depth to work with, so the bit tends to lift and mark the crown; a star bit seats on six faces and pushes down the axis, so the head can be driven hard and still look untouched.
The patch is a decision about the joint, not the screw. Where the joint vibrates or is assembled upside down, a plain thread will back out; the patch holds it. Where the joint is opened often, the patch wears and a thread insert or a mechanical lock is the better answer.
The recorded finish is blue zinc with a nylon patch applied after plating. The zinc protects the steel and gives the bright tone; the patch is a dry film that must not be oiled or over-coated, because its whole function is friction.
| Option | What it does | Effect on thread and patch | Typical use |
|---|---|---|---|
| Blue zinc, nylon patch | Bright finish with a dry friction lock | Patch applied after plating | Vibration joints indoors |
| Blue zinc, no patch | Bright finish, free thread | No patch | Joints adjusted often |
| Black zinc, patch | Dark finish with the same lock | Patch over the passivation | Dark panels |
| Dacromet, patch | Corrosion-resistant flake coating with a lock | Patch on a duller surface | Outdoor and wet joints |
| Stainless, patch | Alloy protection with a lock | Patch over the alloy | Wash-down and coastal work |
The patch and the plating interact in one place: thickness. A heavy zinc deposit on the thread reduces the space the nylon has to work in, so the patch sits higher and binds more than the drawing expects. That is why the plating range is quoted and the first article is checked in the finished condition.
Where the joint is outdoors, blue zinc is the wrong answer and the patch does not change that. A Dacromet or stainless version with the same patch is what holds up, and the drawing should say which environment the screws are for rather than leaving it to the finish name.
Three assemblies where a smooth low head and a vibration-resistant joint are both needed:
| Where it sits | The screw fixes a lid, a bracket or a faceplate where the head is visible on the outside and the joint has to stay tight through handling and transport. |
| When it goes wrong | A sharp-edged head catches on packaging, and a plain thread backs out under the vibration of shipping. |
| Why it happens | The panel is thin, the face is seen, and the product is handled by the end user. |
| What we control | Head diameter and dome checked, recess driven with the production bit, patch zone checked against a sample joint. |
| Where it sits | The screw holds a cover that vibrates with the machine, where the head faces outward and the joint is opened for service. |
| When it goes wrong | A cover that loosens rattles and then comes away, and a cross recess in a low dome marks the paint as it slips. |
| Why it happens | The joint vibrates, the fixing is at the machine face, and the cover is serviced. |
| What we control | Patch position and thread gauge checked, head height checked against the cover. |
| Where it sits | The screw fixes a bracket or a plate on equipment that is carried and used in motion, where nothing should catch and the joint must stay set. |
| When it goes wrong | A protruding or sharp head catches on clothing, and a joint that shakes loose changes the setup. |
| Why it happens | The joint moves and vibrates, the fixing is handled, and the setting matters. |
| What we control | Torque with the patch checked on a sample joint, head dome inspected for burrs. |
Four reasons that matter on a patched star-drive screw, each tied to what the drawing has to prove:
|
Head and patch reviewed together
The head diameter and height, the star recess and the patch zone are reviewed as one set against the joint, so a patch outside the engaged length is raised before the run. Basis: Head and patch reviewed as one set. |
Head, thread and patch in one route
The button head and the star recess are formed in one stroke, the thread is rolled, and the patch is applied after plating on the same route. Basis: One route from wire to patched screw. |
|
Recess and patch checked on the part
The recess is driven with the production bit, and the patch position and length are measured against a sample joint on the first article. Basis: First article driven and patch measured. |
First article to repeat production
The first article fixes the drawing revision, wire heat, die set, thread roll, plating and patch length; repeat orders are compared against that record. Basis: First article signed off before the batch is released. |
Shi Shi Tong forms these button head torx machine screws on a single-die header that upsets the button head and the six-lobe recess in one stroke, rolls the machine thread to a blunt chamfered end, blue zinc plates the parts and applies the nylon patch to a defined thread length. The first part of every run is measured on the head, checked with the production bit and driven into a sample joint, before the batch continues.

|
|
The patch is the operation that decides how the part performs, and it is invisible on the finished screw. It has to sit at the right position over the right length and be dry when packed; a patch a millimetre low does nothing, and one that has been handled with oily gloves binds less than the drawing assumes.
What decides whether button head torx machine screws pass is the head, the recess, the thread, the patch and the plating. The inspection agreement covers those, and the criteria come from the drawing.
Dome profile on the projector |
Thread gauged after plating |
Hardness testing against the property class |
Salt-spray testing of the blue zinc plate |
The patch is checked for position, length and dryness before packing, and the record is kept with the batch. It is the one feature that cannot be seen after the screw is fitted and the one that decides whether the joint stays tight, so it is inspected rather than assumed.
The recess is checked by driving with the production bit and looking at the lobe corners for a polished line. That line appears before the bit actually slips, and on a button head it is also the first thing that shows on a visible fixing.
Every shipment of button head torx machine screws is traceable to the wire it was made from and to the plating and patch records. The grade and heat number are recorded on the material certificate supplied with the parts, and the inspection records follow the criteria agreed on the drawing.
ISO 9001:2015 |
RoHS test report |
Registered trademark |
Patent: security screw and driver |
With each batch we supply the material certificate, the inspection record for the criteria on the drawing and, where it is listed, the third-party report for the material or the plating. The documents carry the drawing revision and the batch number, so the paperwork can be matched to the parts.
More than 8,678 customers in 89 countries and regions have ordered from Shi Shi Tong; 87% of orders come from repeat customers and 56% through referrals. Most projects follow the same route: drawing review, first-article approval, then batches checked against that sample. On a patched screw the first article is driven into a sample joint and then removed, because the patch only proves itself under load. Buyers visit during the process to review samples and to see how the heads are formed.
|
8,678+
customers served
|
87%
of orders from repeat customers
|
56%
of orders through referrals
|
89
countries and regions shipped to
|
Buyers and quality engineers visit for sample review, process discussion and supplier audits; the visit is arranged around production so the header and the plating line can be seen on the day the parts run.
Customer group visit – sample review |
Customer group visit – process discussion |
Customer group visit – factory tour |
Customer visit – project kick-off |
Danish customer – drawing review |
Industry exhibition – meeting customers |
Long Thin Screws: Drawing and Manufacturing Requirements
What to put on the drawing for long, thin parts: datum, shank, thread position and handling.
|
How Long Does It Take to Customize Extra-Long Screws?
Where the time goes in a custom long-screw order, from drawing review to first article.
|
|
M6 Pan Head Hex Socket Machine Screws
Socket-driven pan head screws up to 630 mm with a partial thread.
|
Partial Thread Machine Screws
Partial-thread machine screws with a defined plain shank.
|
Countersunk Socket-Slotted Screws with Locking Patch
Sunk heads with a combined socket-slot drive and a nylon locking patch.
|
|
Custom Extra-Long Machine Screws
Family page: mixed heads, drives and finishes up to 2,000 mm.
|
Extra-Long Low-Profile Phillips Screws
Low heads with a PH recess for recessed covers and black chassis panels.
|
Extra-Long Hex-Head Dacromet Screws
Long hex-head screws with a Dacromet coating for wet or outdoor assemblies.
|
A low domed head, wider than a socket cap of the same thread, with a smooth curved face and no sharp edge.
A low dome has little depth, so a cross bit tends to lift and mark the crown. A star bit seats on six faces and drives without cam-out.
It compresses on engagement and fills the thread clearance, giving a friction lock that resists loosening under vibration.
A limited number of times. The patch is sheared slightly at each assembly, so the lock is strongest on the first fit.
No. It is an indoor finish. For wet or outdoor joints a Dacromet or stainless version with the same patch is the right choice.
Thread size and pitch, head diameter and height, star recess size, thread length, patch position and length, overall length and finish.
